Color |
Black / Green |
Amplifier | Amp Type |
Digital Amp (Stereo) |
RMS Output Power (30 % THD) | Front ch (Both ch driven) |
150 W 75W per channel (30% THD) |
Subwoofer ch |
- |
Total RMS Stereo mode power |
150 W |
PMPO Output Power |
1650 W |
Speaker Unit | Front Speaker |
5 cm Tweeter x2 16 cm Woofer (Hard Press Corrugation) with Dual Drive x1 |
Subwoofer |
- |
Bass Expand |
Bass Reflex Port |
CD / DVD | Playback Disc *1 |
- |
Format |
- |
Internal memory | Capacity |
- |
Media file format support |
- |
USB | USB Port |
USB (Play) |
USB Standard |
USB 2.0 full speed |
Support Format |
MP3 |
Playback |
Y *2 |
Radio | Station Presets | FM |
- |
DAB Plus |
- |
Radio Data System |
- |
Antenna Terminal |
- |
Network | Bluetooth | Version |
Ver. 4.2 |
Class |
Class 1 |
Codec |
SBC |
One Touch Operation from Panasonic TV |
- |
NFC |
- |
Smartphone App | App Name |
Panasonic MAX Juke *3 |
OS | iOS |
Y |
Android |
Y |
Windows Phone |
- |
Other |
- |
Illumination |
Multicolor Edge Illumination (Multiple colors) |
Sound Function | Super Sound EQ, Super Bass Sound | D.Bass |
Y |
D.Bass Beat |
- |
DJ Function | Effect |
- |
Sampler |
- |
Karaoke Jukebox |
- |
DJ Jukebox |
Y |
Preset EQ |
Local Preset EQ (w/o Footaball and Karaoke) |
Manual EQ |
3 Band + Surround |
Room-Filling Expansive Sound |
- |
Low Distortion Technology |
- |
Karaoke |
- |
Terminals | USB Port |
x1 |
Audio IN |
AUX (dia 3.5mm) x1 |
Audio OUT |
- |
Mic Jack |
- |
LAN |
- |
General | Power Supply | AC |
AC 220 - 240 V, 50 Hz |
Power Consumption *4 | Normal Use |
50 W |
Normal Standby |
0.4 W |
Bluetooth Standby |
0.5 W |
Qi Charger | Output Power |
up to 10 W (Fast Charging) *5 |
Timer Function | Sleep |
- |
Clock |
- |
Play Timer |
- |
Rec Timer |
- |
Display Type |
Indication by LED |
Dimmer |
- |
Auto Power OFF |
Y |
External Power Bank Operation |
Y (USB Micro-B) *6 |
Horizontal / Vertical Placement |
Y (Vertical=Main/Operation, Horizontal=Stereo) |
Dimensions, Weight | Main Unit | Dimensions (W x H x D) |
250 X 475 X 265 mm |
Weight |
6.5 kg |
Note: |
*1 Playability may vary depending on the contents, discs and quality of the recording. *2 Only a USB flash drive. Playback is not possible from a portable device (Apple, Android, etc.) using a USB extension cable. *3 Download on Google Play™ and App Store®. *4 Specifications are subject to change without notice. All numbers given here are approximate. *5 For Qi Compatible Smartphones. *6 Use Power Bank with Output Power 2 A or Above, 5 V.Sound Performance: less than 50 % of AC Operation. |
