Rotel RMB-1585 200W x5ch @8ohm Power Amp.
The RMB-1585, Rotel’s flagship theatre amplifier, provides both the massive power and sonic sophistication required by the finest home theatre systems. With five channels, each capable of producing 200 continuous watts each into 8 ohm loads (a full kilowatt of output power!), the RMB-1585 masters any A/V system regardless of speaker load or room size.
But it isn’t just pure output power that distinguishes the RMB-1585. It’s the ability to reproduce both the dynamics of a Hollywood blockbuster and the musical nuances of acoustic instruments that sets it apart. Where does this balance come from? It’s a direct result of Rotel’s celebrated Balanced Design Concept in which circuit topology and parts selection meld in the pursuit of sonic excellence.
The RMB-1585, Rotel’s flagship theatre amplifier, provides both the massive power and sonic sophistication required by the finest home theatre systems. With five channels, each capable of producing 200 continuous watts each into 8 ohm loads (a full kilowatt of output power!), the RMB-1585 masters any A/V system regardless of speaker load or room size.
But it isn’t just pure output power that distinguishes the RMB-1585. It’s the ability to reproduce both the dynamics of a Hollywood blockbuster and the musical nuances of acoustic instruments that sets it apart. Where does this balance come from? It’s a direct result of Rotel’s celebrated Balanced Design Concept in which circuit topology and parts selection meld in the pursuit of sonic excellence.
Information
The pinnacle of performance in Rotel's superb multichannel power amplifier range, the RMB-1585 features 5 x 200 Watts to drive even the largest home theater speaker systems.
Features
5 x 200 Watts of robust power
Class AB amplifier design
Massive power supply using Dual Toroidal
Transformers
High quality slit foil capacitors made in
Britain
Optional rack ears available
Specifications
Dimensions (W × H × D)
431 × 237 × 454mm
17" × 9.4" × 17.9"
17" × 9.4" × 17.9"
Front Panel Height
5U / 221mm (8.75")
Power Requirements
120V, 60Hz
Power Consumption
1100W
Standby Power Consumption
0.5W
Net Weight
36kg (79lbs.)
BTU Rating (4Ω, 1/8th power)
2372 BTU/h
Continuous Power Output
200W/Ch (All channels driven, 8Ω)
Total Harmonic Distortion (THD)
(20Hz–20kHz) <0.03%
Frequency Response
10Hz - 100kHz +0.5, -3dB
S/N Ratio (IHF "A" Weighted)
116dB
Gain
26.5dB
Intermodulation Distortion (60Hz:7kHz, 4:1)
<0.03%
Damping Factor
260
Speaker Impedance
4Ω minimum
Input Sensitivity
Line Level Inputs (RCA): 1.9V
Line Level Inputs (XLR): 3.8V
Input Impedance
Line Level Inputs (RCA): 12kΩ
Line Level Inputs (XLR): 100kΩ
