Rotel A12 60W x2ch @8ohm Integrated Amplifier - Rotel
|
|
Black finish only.
or four payments of $387.25
with
Learn More
Information
A12
Rotel’s A12 integrated amplifier offers impressive audio performance, with 60-watts per channel. Input connections include both analog and digital, along with aptX Bluetooth streaming capability.
The A12 integrated amplifier displays the same clean lines and intuitive operation as the A14 with output power rated at 60 watts per channel RMS into 8 ohms. Rotel engineers begin their quest for uncompromising audio performance at the power supply. This is the heart of an amplifier and an area where considerable time and investment is spent. Rotel manufactures its own toroidal transformers in-house to high tolerances using raw materials selected from proven, trusted suppliers. The result is a rugged power supply that won’t easily distort the music under dynamic conditions or with diŽfficult speaker loads.
Rotel’s A12 integrated amplifier offers impressive audio performance, with 60-watts per channel. Input connections include both analog and digital, along with aptX Bluetooth streaming capability.
2 x 60 Watts of robust Class AB power
Moving magnet phono input for turntable connection
Bluetooth with aptX
Wolfson premium 24-bit/192kHz Digital to Analog Converter
Specifications
CONTINUOUS POWER OUTPUT
60W/Ch (All channels driven, 8Ω)
TOTAL HARMONIC DISTORTION (THD)
(20Hz–20kHz) <0.03%
FREQUENCY RESPONSE
Line Level Inputs: 10Hz - 100kHz ±0.5dB
Digital Inputs: 10Hz - 80kHz ±3dB
Phono Input: 20Hz - 20kHz ±0.5dB
S/N RATIO (IHF "A" Weighted)
Line Level Inputs: 100dB
Digital Inputs: 103dB
Phono Input: 90dB
DIMENSIONS (W × H × D)
430 × 93 × 345mm
17" × 3.6" × 13.5"
FRONT PANEL HEIGHT
80mm (3.15")
POWER REQUIREMENTS
120V, 60Hz
POWER CONSUMPTION
230W
STANDBY POWER CONSUMPTION
<0.5W
NET WEIGHT
8kg (17.6lbs.)
BTU RATING (4Ω, 1/8th power)
517 BTU/h
INTERMODULATION DISTORTION (60Hz:7kHz, 4:1)
<0.03%
DAMPING FACTOR
220
SPEAKER IMPEDANCE
4Ω minimum
INPUT SENSITIVITY
Line Level Inputs: 200mV
Digital Inputs: 0dBfs
Phono Input (MM): 3mV
INPUT IMPEDANCE
Line Level Inputs: 24kΩ
Digital Inputs: 75Ω
Phono Input (MM): 47kΩ
INPUT OVERLOAD
Line Level Inputs: 4V
Phono Input: 50mV
PREOUT LEVEL
1V
OUTPUT IMPEDANCE
470Ω
TONE CONTROLS
±10dB at 100Hz / 10kHz
COAX/OPTICAL DIGITAL INPUT SIGNALS
LPCM (Up to 24-bit/192kHz)
PC-USB
USB Audio Class 1 (up to 24/96)
USB Audio Class 2 (up to 24/192)
